Thermal Application grade CVD

With proper controlled growth, hardness of every thermal grade CVD is being produced to meet the demand of clients.

Make an enquiry
Category:

Additional information

Thickness, mm

0.5

Type

Ila

Face orientation

(100)

Edge Orientation

(110)

Crystallography

Multi-sectorial

Roughness, Ra

~5 nm

Miscut

90 +/- 3 00B0

Parallelism

+/- 0.02

Lateral Tolerance, mm

+/- 0.05

Thickness Tolerance, mm

+/- 0.05

Edges

Ploshed

Edges Features, mm

< 0.02

Laser

Water-jet

Boron Concentration, ppb

~50

Nitrogen Concentration, ppb

~10

Dislocations density, cm2

~10 2-5

Thermal conductivity, Wt/mK

~2200

Absorption coefficient, cm-1

0.0045

Length/Width

3.00mm – 20.00mm

Height

0.50mm – 8.00mm
